Lilliput Q15 15.6 Inch Broadcast Production Studio Monitor

Lilliput Q15 15.6 Inch Broadcast Production Studio Monitor

Normaler Preis $1,699.00
Normaler Preis Verkaufspreis $1,699.00
Sale Ausverkauft
inkl. MwSt. Versand wird beim Checkout berechnet

100 auf Lager

PRODUCT DESCRIPTION

Q15 15.6 Inch Broadcast Production Studio Monitor

The Lilliput Q15 15.6" 12G-SDI HDMI 2.0 Broadcast Production Studio Monitor is a stable work horse machine, packed with features and facilities for the serious photographer, videographer, or cinematographer. Compatible with a multitude of inputs - and featuring an optional 12G SDI SFP Fibre Optic input connection for broadcast quality monitoring, It also features Audio Vectoring using a Lissajous graph shape allowing you to visualise the depth and balance of a stereo recording - a first for a Lilliput monitor.

  • The Lilliput Q15 is a stable work horse machine, packed with features and facilities for the serious photographer, videographer, or cinematographer. Compatible with a multitude of inputs - and featuring the option of a 12G SDI SFP Fiber Optic input connection for broadcast quality monitoring, It also features Audio Vectoring using a Lissajous graph shape allowing you to visualize the depth and balance of a stereo recording - a first for a Lilliput monitor.
  • The 12G SDI inputs allow the units allow for multiple configurations of input. Single Link, Dual Link, and Quad link inputs mean you can use a either a single input or conjoined inputs to make up your 4K video input signal. This opens up the input workflow for the multiple types of camera to be attached into the monitor depending on the usage and configuration of the video capture environment.
  • Audio Vectoring
  • With HDR activated (HDR 10), the display produces a much greater dynamic range of luminosity, allowing lighter and darker details to be displayed more clearly - effectively enhancing the overall picture quality.

DISPLAY Panel 15.6"
Physical Resolution 3840x2160
Aspect Ratio 16:09
Brightness 330cd/m2
Contrast 1000:1
Viewing Angle 176°7 176°(H/V)
HDR ST2084 300/1000/10000/HLG
Supported Log formats SLog2 / SLog3 / CLog / NLog / Arri Log / JLog or User...
Look up table (LUT) support 3D LUT (.cube format)
Technology Calibration to Rec.709 with optional calibration unit
VIDEO INPUT SDI 2x12G, 2x3G (Supported 4K-SDI Formats Single/Dual/Quad Link)
SFP 1x12G SFP+(Fiber module for optional)
HDMI 1xHDMI 2.0
VIDEO LOOP OUTPUT SDI 2x12G, 2x3G (Supported 4K-SDI Formats Single/Dual/Quad Link)
HDMI 1xHDMI 2.0
SUPPORTED FORMATS SDI 2160p 24/25/30/50/60, 1080p 24/25/30/50/60, 1080pSF 24/25/30, 1080i 50/60, 720p 50/60...
SFP 2160p 24/25/30/50/60, 1080p 24/25/30/50/60, 1080pSF 24/25/30, 1080i 50/60, 720p 50/60...
HDMI 2160p 24/25/30/50/60, 1080p 24/25/30/50/60, 1080i 50/60, 720p 50/60...
Audio In/Out
(48kHz PCM Audio)
SDI 16ch 48kHz 24-bit
HDMI 8ch 24-bit
Ear Jack 3.5mm
Built-in Speakers 2
REMOTE CONTROL RS422 In/out
GPI 1
LAN 1
POWER Input Voltage DC 12-24V
Power Consumption .5.32.5W (15V)
Compatible batteries V-Lock or Anton Bauer Mount
Input voltage (battery) 14.8V nominal
ENVIRONMENT Operating Temperature 0°C-40°C
Storage Temperature -20°C~60°C
OTHER Dimension(LWD) 393mm x 267mm x 51.4mm
Weight 2.9kg
